Heavy duty Automatic plate edge beveling machine
Heavy duty Automatic plate edge beveling machine
Heavy duty Automatic plate edge beveling machine
Heavy duty Automatic plate edge beveling machine
Heavy duty Automatic plate edge beveling machine
Heavy duty Automatic plate edge beveling machine
Model
WP-100

Item specifics

Color
Silver
Volate
AC380V/50hz
Application material
Stainless steel,alloy steel,carbon steel,Composite
Clamp thickness
1-100mm
Spindle Speed
750-1440r/min (adjustable)
Bevel Angle
0-90° (adjustable)
Power
6520 w

Review

Description

INTRODUCTION
plate cutting machine
DETAILS
WP-100 Heavy duty Automatic plate edge beveling machine is a new model specially for heavy duty metal sheets for fabrication preperation. It is available for plate thickness 8-100mm, bevel angel 0 to 90 degree for vary type of welding joint such as V/Y,U/J, 0/90 degree. Max bevel width could reach 100mm.

FEATURES

WP-100 edge milling machine convenient and simple operation. The finish of groove is as high as Ra3.2-6.3. The milling machine equiped with commonly used CNC blades to make the customers use the costs more cheaply.

STANDARD ACCESSORIES
Machine body
1 Set
Blade
1 pc
Tool box  with wrenches
1 Set
Pipe plate Milling Machine
Pipe plate Milling Machine
Pipe plate Milling Machine
Pipe plate Milling Machine
 PARAMETER
Plate cutting machine
Model
WP-100
Power
AC 380V/50hz
Clamp thickness
8-100mm
Total
6520W
Clamp width
>200mm
Spindle Speed
750-1440r/min
Clamp Length
>300mm
Feed Speed
0-1500r/min
(adjustable)
Work Height
850-900mm
Bevel Wdith
1-100mm
Processing
materials
Carbon Steel

Single Bevel Width
1-30mm
Stainless Steel
Bevel Angle
0-90°
Aluminum alloy
Automatic clamping (optional)
Composite Plate
Plate cutting machine
Model
WP-100B
Power
AC 380V/50hz
Clamp thickness
6-80mm
Total
6520W
Clamp width
>100mm
Spindle Speed
750-1440r/min
Clamp Length
>300mm
Feed Speed
0-1500r/min
(adjustable)
Work Height
820-860mm
Bevel Wdith
0-80mm
Processing
materials
Carbon Steel

Single Bevel Width
135mm
Stainless Steel
Bevel Angle
0-90°
Aluminum alloy
Automatic clamping (optional)
Composite Plate
 PRODUCT DETAILS MAP
Pipe Beveling Machines
Handle Wheel
Adjust Feed Volume
CNC Cutter
High Precision

Pipe Beveling Machines
Pipe Beveling Machines
New Type Cutter
More accurate when processing 90°
Angle Scale
Adjust Bevel Angle

Pipe Beveling Machines
Pipe Beveling Machines
Rubber Wheel Clamp
More tighter Protect plate surface not damage
CNC Displayer
Accurate Adjust Feed Speed
Equip with Manual clamp
Auto clamp function is optional
Pipe Beveling Machines
Pipe Beveling Machines
Pipe Beveling Machines
Pipe Beveling Machines
Pipe Beveling Machines
