WELDY mini welder Geo2
WELDY mini welder Geo2
WELDY mini welder Geo2
WELDY mini welder Geo2
WELDY mini welder Geo2
WELDY mini welder Geo2
Model
Geo2

Item specifics

Color
black
Power supply
220V,50/60Hz, 1PH
Power
800w
Wedge temperature max
480ºC
Welding width
2×12mm
Welding speed
0.4-7.5m/min
Material thickness
0.5-1.5mm
Max. overlap
100mm
Emission level
60dB

Review

Description

INTRODUCTION
315mm Electrofusion Machine
Handheld Plastic Extrusion Welder
This quick and lightweight welding machine is ideal for geomembranes from 0.5 to 1.5 mm thick (HDPE 0.4 - 1.0mm; TPO 0.7 - 1.5 mm). The miniwelder geo2 can be used to weld fish farm and water tanks, in foundation sealing and many other industrial areas.The miniwelder geo2 distinguishes itself through its revolutionary drive technology and its intuitive use. Temperature and speed easily can be activated and deactivated by means of two buttons, and adjusted using two dials. The current process status is displayed by two LEDs.
315mm electrofusion welding machine
electrofusion welding machine
electrofusion welding machine
electrofusion welding machine
 PARAMETER
HDPE electrofusion welding machine
Model
Geo2
Power
800W
Wedge Temperature Max
 480℃
Welding Width
2*12mm
Welding Speed
0.4-7.5m/min
Material thickness
0-1.5mm
Frequency
50HZ
Max. overlap
100mm
Emission level
60dB
Mark of conformity
CE
Net weight
6.5kg
Packing Size
38*32*28cm
 PRODUCT DETAILS MAP
PE electrofusion machine
Digital temperature regulator 50-450℃

Temperature control


PE electrofusion machine
PE electrofusion machine
The Geo2 automatic welder is equipped with a powerful and durable motor

Tension Lever


PE electrofusion machine
PE electrofusion machine
The tool box
